Home
> DVD > DVR-A05 |
|
|
|
|
|
|
 |
|
|
|
Write Support
*Only when Certified 4x or 2x media is used |
DVD-R 1x, 2x* and 4x*
DVD-RW 1x and 2x*
CD-R 16x, 12x, 8x and 4x
CD-RW 8x and 4x |
| Read Support |
DVD-ROM & DVD-Video (single & dual layers)
DVD-R, CD-ROM Mode1
CD-ROM XA Mode2 (form 1, form 2)
Photo CD (single & multiple sessions)
CD-DA
CD-R
CD-RW
DVD-RW
|
| Read Speed |
DVD-Rom(Single) |
Max. 12x CAV (16.62MB/s) |
| DVD-ROM(Dual) |
Max 8x CAV (11.08MB/s) |
| DVD-R,DVD-RW |
Max 6x CAV (8.31 MB/s) |
| CD-ROM |
Max. 32x CAV (4.92MB/s) |
| CD-R,CD-RW |
Max. 32x CAV (4.92MB/s) |
| CD-Audio |
Max. 32x CAV (4.92MB/s) |
| Video-CD |
4x CLV (0.60MB/s) |
| Access Time(Random Average) |
DVD |
140 msec |
| CD |
130 msec |
| Recording Method |
Disc-at-once and incremental write
Re-Recordable |
| Mounting Orientation |
Horizontal only |
| Interface |
ATAPI (PIO Mode 4, Multi Word DMA Mode 2, Ultra DMA Mode2) |
| Buffer Memory |
2 MBytes (Write) 512KBytes (Read) |
| Audio Out |
Analog Out (CD-Audio only) |
Dimensions
(W x H x D) |
148 mm x 42.3 mm x 198 mm |
|
|
|
 |
|
